A90 POS Terminal--Shenzhen Sumcco Information Co., Ltd

A90

A90 Specification
Processor	Security quad-core CPU with 32 bits high performance
Memory	RAM 1G + ROM 2G, ( optional to 2G + 16G )
Operation System	Android 7.x security OS
Extensible Memory	Micro SD (TF) port, maximum 32 GB
Display Screen	5.5 inch IPS capacitive touch screen, support E-signature 1280*720
Keys	1 physical button (power ON/OFF) 3 touch buttons (Menu, Back, Home)
Pin Pad	Built-in Pin pad.
Printer	Built-in high speed thermal printer. Supports BT printingSpeed: >18 lines/sec Paper roll width: 58mm. Diameter: 40mm Trouble free printing guarantee: >100K times, >50km
Cameras	Front camera: fixed focus, 2 mega-pixel; Rear camera: auto-zoom, 5 mega-pixel with flash
Mag-stripe card reader	Encrypted magnetic head, supports 1/2/3 track and bi-direction card reading Confirm to ISO7811 and 7812 standards
Contact IC card reader	Supports 1.8V/3V/5V IC cards Comply to ISO 7816, EMV, and PBOC standards
Contactless card reader	13.56MHz, supports ISO 14443, Type A/B MiFare card
Audio system	Built-in speaker, buzzer, and microphone
Multimedia	Supports 1080p video play, 720p video recording, front 2 mega-pixel and rear 5 mega-pixel photograph Supports audio play and voice recording
Indicator lights	4 contactless LED indicator lights
PSAM card	2 SAM card slots, comply with ISO 7816
SIM card	2 SIM card slots
Wireless communication	4G network, and is compatible with 2G/3G network Supports DSDS, Supports data service WiFi 802.11a/b/g/n, supports 2.4G and 5G dual frequency BluetoothV4.0,supportsBLE
Peripheral Ports	1 Micro USB2.0, DC JACK, Pogo Pin
Barcode reader	Supports 1D and QR code reading
GPS	Built-in GPS, supports A- GPS
Physical	Dimension: 200mm×80mm×56/25mm Weight: 418g（includes battery）
Environment	Operating temperature: -20℃～60℃ Storage temperature: -40℃～80℃ Relative humidness: 10%～90%( No condensing)
Battery	Li-battery, 3.8V/6000mAh
Anti-static	±8KV contact discharge ±15KV air discharge
Certifications	PCI PTS 5.x , EMV L1 & L2 , EMV CL1 MasterCard PayPass VISA PayWave PBOCL1&L2 America Express JCB LoA Discover D-PAS CCC
